1996 Acura RL(United States)

The luxury division of Honda, Acura sells a full lineup of models ranging from a compact sedan to a large crossover with seven seats in three rows. Though it's intended to compete with luxury brands, its pricing and perception reflect a premium brand. Acura has emphasized sportiness, bolstered by Type-S versions of some models, but its reliance on front-wheel drive has held it back in the race against some competitors, including BMW and Infiniti. A shift toward all-wheel drive in some models has raised Acura's performance credibility to a degree. Likewise, the Type-S designation represents a more modest approach than competitors such as BMW's M division, Mercedes-Benz's AMG and Cadillac's V-Series.Car models in the U.S. market include the compact TSX sedan and upcoming wagon and the midsize TL sedan (all based loosely on the Honda Accord) and the RL, which is the flagship sedan but is smaller than most competing full-size sedans. Crossovers include the compact five-seat RDX, seven-seat MDX (which predated its Honda Pilot sister model) and a sporty five-seat derivation called the ZDX.Honda and Acura are headquartered in Japan.

• BODY / EXTERIOR DESIGN / DIMENSIONS

Body Type:Saloon (sedan) 4 doors / 4 seats
Weight:n/a
Length:4973 mm
Height:1455 mm
Wheelbase:2800 mm
Front Track:1576 mm
Rear Track:1585 mm
Ground Clearance:145 mm
Fuel Capacity:73 liters

• ENGINE SPECIFICATIONS

Engine location:front
Engine alignment:transverse
Drive Wheels:All wheel drive
Steering:rack & pinion VPAS
Fuel Supply System:Honda PGM-Fi fuel injection
Max Power:304HP (224 kW) @ 6300 rpm
Max Torque:368Nm @ 5000 rpm
CO2 Emissions:n/a
Engine Coolant:water
Displacement:3664 cc
Bore:90 mm
Stroke:96 mm
Cam Design:SOHC - Single Overhead Camshaft
Cylinders:n/a
Valves per cylinder:4
Total Valves:24
Compression Ratio:11.2:1
Aspiration:Normal

• CHASSIS / BRAKES / SUSPENSIONS

Front Brakes:VeDi
Rear Brakes:VeDi-S-ABS
Standard Wheels:8 x 18 / 8 x 18
Standard Tyres:Michelin Pilot HX MXM4 P24545 R 18 96V / Michelin Pilot HX MXM4 P24545 R 18 96V
Suspension Front:I.DW.CS.ARB.
Suspension Rear:I.MultiLi.CS.ARB.

• TRANSMISSION

Transmission:6 speed automatic
Number of gears:6

• PERFORMANCE

Acceleration 0-100 Km/h:
Acceleration 80-120 Km/h:
Top Speed:n/a

• FUEL CONSUMPTION

City:13.84 l/100km
Road:9.8 l/100km
Mixt:11.76 l/100km

• BODY / EXTERIOR DESIGN / DIMENSIONS

Body Type:Saloon (sedan) 4 doors / 4 seats
Weight:n/a
Length:4973 mm
Height:1455 mm
Wheelbase:2800 mm
Front Track:1576 mm
Rear Track:1585 mm
Ground Clearance:145 mm
Fuel Capacity:73 liters

• ENGINE SPECIFICATIONS

Engine location:front
Engine alignment:unknown
Drive Wheels:Rear wheel drive
Steering:n/a
Fuel Supply System:Honda PGM-Fi fuel injection
Max Power:304HP (224 kW) @ 6300 rpm
Max Torque:368Nm @ 5000 rpm
CO2 Emissions:n/a
Engine Coolant:water
Displacement:3664 cc
Bore:90 mm
Stroke:96 mm
Cam Design:SOHC - Single Overhead Camshaft
Cylinders:n/a
Valves per cylinder:4
Total Valves:24
Compression Ratio:11.2:1
Aspiration:Normal

• CHASSIS / BRAKES / SUSPENSIONS

Front Brakes:VeDi
Rear Brakes:VeDi-S-ABS
Standard Wheels:8 x 18 / 8 x 18
Standard Tyres:Michelin Pilot HX MXM4 P24545 R 18 96V / Michelin Pilot HX MXM4 P24545 R 18 96V
Suspension Front:I.DW.CS.ARB.
Suspension Rear:I.MultiLi.CS.ARB.

• TRANSMISSION

Transmission:5 speed automatic
Number of gears:5

• PERFORMANCE

Acceleration 0-100 Km/h:
Acceleration 80-120 Km/h:
Top Speed:n/a

• FUEL CONSUMPTION

City:n/a
Road:n/a
Mixt:n/a

• BODY / EXTERIOR DESIGN / DIMENSIONS

Body Type:Saloon (sedan) 4 doors / 5 seats
Weight:1820 Kg
Length:4917 mm
Height:1452 mm
Wheelbase:2800 mm
Front Track:1576 mm
Rear Track:1585 mm
Ground Clearance:145 mm
Fuel Capacity:73 liters

• ENGINE SPECIFICATIONS

Engine location:front
Engine alignment:transverse
Drive Wheels:All wheel drive
Steering:rack & pinion VPAS
Fuel Supply System:Honda PGM-Fi fuel injection
Max Power:294HP (216 kW) @ 6200 rpm
Max Torque:347Nm @ 5000 rpm
CO2 Emissions:n/a
Engine Coolant:water
Displacement:3471 cc
Bore:89 mm
Stroke:93 mm
Cam Design:DOHC - Double Overhead Camshaft (per bank)
Cylinders:n/a
Valves per cylinder:4
Total Valves:24
Compression Ratio:11:01
Aspiration:Normal

• CHASSIS / BRAKES / SUSPENSIONS

Front Brakes:VeDi
Rear Brakes:VeDi-S-ABS
Standard Wheels:8.0 x 17 / 8.0 x 17
Standard Tyres:Michelin P24550 R 17 98V / Michelin P24550 R 17 98V
Suspension Front:I.DW.CS.ARB.
Suspension Rear:I.MultiLi.CS.ARB.

• TRANSMISSION

Transmission:5 speed automatic
Number of gears:5

• PERFORMANCE

Acceleration 0-100 Km/h:
Acceleration 80-120 Km/h:
Top Speed:n/a

• FUEL CONSUMPTION

City:n/a
Road:n/a
Mixt:n/a

• BODY / EXTERIOR DESIGN / DIMENSIONS

Body Type:Saloon (sedan) 4 doors / 4 seats
Weight:1768 Kg
Length:4994 mm
Height:1384 mm
Wheelbase:2911 mm
Front Track:1549 mm
Rear Track:1539 mm
Ground Clearance:124 mm
Fuel Capacity:68 liters

• ENGINE SPECIFICATIONS

Engine location:front
Engine alignment:transverse
Drive Wheels:Front wheel drive
Steering:rack & pinion VPAS
Fuel Supply System:Honda PGM-Fi
Max Power:228HP (167 kW) @ 5200 rpm
Max Torque:313Nm @ 2800 rpm
CO2 Emissions:n/a
Engine Coolant:water
Displacement:3474 cc
Bore:90 mm
Stroke:91 mm
Cam Design:DOHC - Double Overhead Camshaft (per bank)
Cylinders:6 IN V
Valves per cylinder:4
Total Valves:24
Compression Ratio:9.6:1
Aspiration:Normal

• CHASSIS / BRAKES / SUSPENSIONS

Front Brakes:VeDi
Rear Brakes:Di-S-ABS
Standard Wheels:7JJ x 16 / 7JJ x 16
Standard Tyres:Michelin MXM4 P225/55 R 16 94V / Michelin MXM4 P225/55 R 16 94V
Suspension Front:I.DW.CS.ARB.
Suspension Rear:I.DW.CS.ARB.

• TRANSMISSION

Transmission:automatic
Number of gears:4

• PERFORMANCE

Acceleration 0-100 Km/h:
Acceleration 80-120 Km/h:
Top Speed:n/a

• FUEL CONSUMPTION

City:8.5 l/100km
Road:6.5 l/100km
Mixt:5.4 l/100km

• BODY / EXTERIOR DESIGN / DIMENSIONS

Body Type:Saloon (sedan) 4 doors / 5 seats
Weight:1750 Kg
Length:4995 mm
Height:1435 mm
Wheelbase:2910 mm
Front Track:1549 mm
Rear Track:1539 mm
Ground Clearance:124 mm
Fuel Capacity:68 liters

• ENGINE SPECIFICATIONS

Engine location:front
Engine alignment:transverse
Drive Wheels:Front wheel drive
Steering:rack & pinion VPAS
Fuel Supply System:Honda PGM-Fi
Max Power:213HP (157 kW) @ 5200 rpm
Max Torque:304Nm @ 2800 rpm
CO2 Emissions:n/a
Engine Coolant:water
Displacement:3474 cc
Bore:90 mm
Stroke:91 mm
Cam Design:DOHC - Double Overhead Camshaft (per bank)
Cylinders:n/a
Valves per cylinder:4
Total Valves:24
Compression Ratio:9.6:1
Aspiration:Normal

• CHASSIS / BRAKES / SUSPENSIONS

Front Brakes:VeDi
Rear Brakes:Di-S-ABS
Standard Wheels:7JJ x 16 / 7JJ x 16
Standard Tyres:Michelin MXM4 P21560 R 16 94V / Michelin MXM4 P21560 R 16 94V
Suspension Front:I.DW.CS.ARB.
Suspension Rear:I.DW.CS.ARB.

• TRANSMISSION

Transmission:4 speed automatic
Number of gears:4

• PERFORMANCE

Acceleration 0-100 Km/h:
Acceleration 80-120 Km/h:
Top Speed:n/a

• FUEL CONSUMPTION

City:n/a
Road:n/a
Mixt:n/a

• BODY / EXTERIOR DESIGN / DIMENSIONS

Body Type:Saloon (sedan) 4 doors / 5 seats
Weight:1660 Kg
Length:4955 mm
Height:1385 mm
Wheelbase:2910 mm
Front Track:1550 mm
Rear Track:1540 mm
Ground Clearance:125 mm
Fuel Capacity:68 liters

• ENGINE SPECIFICATIONS

Engine location:front
Engine alignment:transverse
Drive Wheels:Front wheel drive
Steering:rack & pinion VPAS
Fuel Supply System:Honda PGM-Fi fuel injection
Max Power:213HP (157 kW) @ 5200 rpm
Max Torque:304Nm @ 2800 rpm
CO2 Emissions:n/a
Engine Coolant:water
Displacement:3474 cc
Bore:90 mm
Stroke:91 mm
Cam Design:SOHC - Single Overhead Camshaft
Cylinders:n/a
Valves per cylinder:4
Total Valves:24
Compression Ratio:9.6:1
Aspiration:Normal

• CHASSIS / BRAKES / SUSPENSIONS

Front Brakes:VeDi
Rear Brakes:Di-S-ABS
Standard Wheels:6½JJ x 16 / 6½JJ x 16
Standard Tyres:P21560 R 16 94V / P21560 R 16 94V
Suspension Front:I.DW.CS.ARB.
Suspension Rear:I.DW.CS.ARB.

• TRANSMISSION

Transmission:4 speed automatic
Number of gears:4

• PERFORMANCE

Acceleration 0-100 Km/h:
Acceleration 80-120 Km/h:
Top Speed:n/a

• FUEL CONSUMPTION

City:n/a
Road:n/a
Mixt:n/a
